Year 2013
Web width: 340mm
Print width: 330mm
Die cutting width: 330mm
1 unwind unit to take reels up to 850mm dia.
Web Guide
1 variable infeed
1 integration to run in-line with digital print engine/tower
1 servo inserting system to allow for pre-printed material to register with the converting units.
Vetaphone corona surface treater
1 plasma surface unit
1 flexographic full and semi-rotary unit for printing, varnishing and application of special features/cold foil etc.
1 cold foil unit and lamination unit
1 GEW UV unit for curing of inks and coatings
1 control feed unit
1 full rotary and semi rotary die-cutting unit
Waste Rewind
1 side trimming unit
1 slitting station
1 outfeed unit
2/dual rewind unit to allow for two separate reels to be rewind top and bottom
The print station is full & semi rotary, which allow the print units to print any size Print length /repeat without changing the print cylinder.  However, the speed is then reduced but it is excellent technology to produce jobs very quickly.  If a higher speed is required, then a 1:1 ratio print & die cutting cylinder will be required.

OFFLINE machine (although machine was used inline by owner). This machine is ideal to combine with ABG Turret Rewinder Vectra.

Tooling including:
1 printing cylinder
1 varnish cylinder
1 anilox cylinder
1 204z magnetic die cutting cylinder
