Apollo SR Slitter/Rewinder
Web width of 330mm (SR330) wide: The all versatile slitter rewinder to partner any label press for the production of final reels of labels. Easy loading on all pneumatic shafts for unwind and rewind - rotary slitting blades - edge guides - perfect tension control - waste extraction - length and label count and lots more.
1 x Unwind cantilever unit to take 500mm dia. rolls with pneumatic shaft of 76mm
1 x Tension control with magnetic clutch
1 x Web guide with floating shaft for accurate web control, including 2 edge sensors
1 x 3 format draw path roller system for accurate conversion of paper, laminates and foil
1 x Splicing table
1 x Slitting station with quick change top and bottom rotary slitting blades with scissor type
slitting
1 x Sideway adjustment of material and slitting station
1 x 2 cantilever duplex pneumatic product rewind shafts with 1 size of shafts included and
magnetic clutches for accurate rewinding, with quick change of shafts for different sizes
1 x Trim extraction unit for extracting trim waste
1 x Motor with drive
1 x Automatic operator control unit for speed, length and label count
- Minimum cutting width 10mm
- Cutting precision 0.2mm
- Slitting speed, depending on material, between 70-120m/min.
- Dimensions 1500mm (L) x 1000mm (W) x 1200mm (H)
- Weight 430kg
- Power: 2kw, 3 phase, 380V, 50/60HZ
APOLLO SR 330
