Signal SRD-SX 380

REF: BM00649

Year: 2021

Maximum Material Width: 380mm (14.9”)
Maximum Converting Width: 370mm (14.57”)
Maximum die-cutting Width: 370mm (14.57”)
Maximum die-cutting Length: 370mm (14.57”)

Description:- To generate further converting solutions on a pre-printed reels of material with the following specification.

Maximum Unwind Diameter: 31.5” (800mm)
Top Rewind Diameter: 23.6” (600mm) or
Bottom Rewind Diameter: 31.5” (800mm)
Ground Helical Gears: Hardened
Mechanical Speed: 394fpm (120m/min)
Machine power: 80kw
Full load amps: 210
Power supply 380V +(-) 10%, 3 phase, 50/60Hz
UV power: 12kw
Full load amps: 30
Lubricating System: Automatic
Control Panel: In the front of the Press
Air Pressure: 100PSI (0.6Mp)
Substrate: 50-250gsm – paper
20-50micron – film
Print Registration: ±0.15mm
Full Rotary Print Speed: 120m/min
Full Rotary Die-Cutting
Speed: 120m/min
Semi-Rotary Print Speed: 60m/min
Semi-Rotary Die-Cutting
Speed: 60m/min
Cold Foil Unit Speed: 60 to 80m/min (Subject to the material and adhesives used)
Hot Foil Stamping Speed: 100 imp/min
Hot Stamping Register: ±0.15mm
Flat Die-Cutting Speed: 400 imp/min(120m/min)
Flexo-Plate Thickness: 1.14mm (or specify)
Flexo-Adhesive Mounting
Tape Thickness: 0.38mm (or specify)
Flat Die-Cutting Plate Thickness: Universal gauges (Variable adjustment to Die-Plates)

1 x Unwind Reel Stand for Quick loading of reels (up to 800mm dia) on 76mm Air Shafts to Unwind clockwise and anti-clockwise
1 x Electronic Web Guide for accurate guiding of material
1 x Infeed with servo registered drive to interface with other units through converting register
1 x Full and Semi-Rotary servo drive print station including Water chilled impression cylinder
- The Flexo print station will run Full Rotary with matching print station and also Semi-Rotary with unequal print cylinders.
- Will print, coat and spot varnish in register
- Including 1 x Print Cylinder 140T

1 x Cold Foil and lamination Unit (Foil Unwind and Rewind)
1 x Full rotary flexo print station (including Mercury UV)
1 x SureMax MV (Mercury Lamp) including Universal Drive to allow for future installation or replacement with LED UV Lamp (no need to replace the drive)
- MC UV Lamp: 7.5kw
- LED UV Lamp: 3.2kw

1 x Servo Drive – High Speed Flow type Hot Foil stamping unit and Die-Cutting with heated platen with temperature control, linear stamping and cross stamping (to allow for multi-coloured Hot foil to applied in 1 pass) Die-Cutting can also be done on this unit.
1 x Servo Drive High Speed Flow type Flat Die-Cutting unit
1 x Slitting Station with 8 Rotary knives
1 x High Speed Snowball Waste Rewind unit
1 x Outfeed Unit
2 x Independent Product Rewind shafts (Dual rewind)

TOOLING INCLUDED
