ULTRACOAT 900 FST

REF: BM00235

Sheet fed flexographic coater suitable for coating a wide range of varnishes, adhesives and special coatings.
Maximum coating thickness is 15 um
Sheet Size: Max 640 x 940mm (25” x 37”)
Sheet Size: Minimum 330 x 406mm (13” x 16”)
Maximum image Area: 630 x 930mm (24.8” x 36.625”)
Plate Size: 730 X 945mm (28.8 x 37.25”)
Blanket Size: 730 x 945mm (28.8” x 37.25”)
Plate Cylinder Undercut: Total 2.5mm
Weight Approx: 4500kg (Coating Unit)
Space Required: 3035 x 2782 x 1965 (119.5” x 109.5” 77.35”)
Maximum Mechanical Speed: 10,000 SPH
Electrical Power Consumption: 39.00 KW with UV Lamp / 51 KW with 2 UV Lamps (3 phase)
Height of Feed Pile: 1050mm (41.14”)
Height of Delivery: 1000mm (40”)
Diameter of Impression Cylinder: 320mm
Photopolymer Plate: 1.7mm
Total Makeready (including plate / blanket): 2.5mm
Distortion: (1.7mm plate) 0.9853%
